| DC Output Power |
30 kW |
| Battery Capacity |
20 kWh |
| Battery Chemistry |
LFP (Prismatic Grade A) |
| Battery Cycle Life |
4000+ cycles at 80% DoD |
| BMS Type |
Active, cell-level monitoring |
| SOC Accuracy |
±2 % |
| Connectors |
CCS2 + CHAdeMO |
| Solar Input (optional) |
5 kW via MPPT |
| Charging Modes |
Grid, Battery-only, Solar-assist |
| Communication |
OCPP 2.0 + ISO 15118-2 |
| Connectivity |
4G LTE Dual SIM + Wi-Fi + GigE |
| Display |
7-inch IPS Touchscreen |
| Payment Methods |
RFID, NFC, QR, UPI |
| Protection Rating |
IP55 |
| Dimensions (W×H×D) |
720×1820×560 mm |
| Weight |
310 kg |
| Certification |
BIS, CE, IEC 62196-3, UN 38.3, IEC 62619 |
